Luxury isn’t meant to be desired - it’s meant to be attainable.

Designed in Lake Tahoe, USA, the ZLINE 30" 16.1 cu. ft. Panel Ready Built-In 2-Door Bottom Freezer Refrigerator with Internal Water and Ice Dispenser provides a professional culinary experience by pairing unmatched performance with timeless style.

Achieve ZLINE Attainable Luxury® excellence with innovative features designed to enhance your kitchen’s capability.

Features

• Panel-Ready Built-In Design - Create a custom look in your kitchen with a true flush installation designed to provide a custom, seamless look
• Adjustable Refrigerator Temperature - Create the perfect cooling environment for your items with temperatures ranging from 35°F to 46°F
• Adjustable Freezer Temperature - Achieve the perfect cooling environment for your frozen items with temperatures ranging from -11°F to 5°F
• Super Cool and Super Freeze Modes - Save time and quickly chill food with unique functions that automatically set the fridge temperature to 35°F and freezer to -12°F
• Digital ChillControl - Easy-to-use LED display allows you to quickly change temperatures for the refrigerator, crisper drawer, and freezer and navigate menu options to change the refrigerator to vacation, sabbath or eco modes
• Soft-Shut Technology - Smooth-closing refrigerator doors and drawers seamlessly open and close ensuring heavily used fridge components are enjoyed for years to come
• CrispControl Drawer - Proprietary crisper drawer features an adjustable temperature zone that allows fruits and vegetables to retain freshness longer
• Adjustable Shelves - Easily store larger items with spill-resistant adjustable glass shelving
• Dual Cooling - Separate refrigerator and freezer cooling systems ensures air and odors are not mixed between compartments and provide fast and efficient cooling
• Internal Water Dispenser and Ice Maker - Delivers fresh, filtered water discreetly within the refrigerator and up to 4 lbs of ice per day with an automatic ice maker in the freezer
• Multiple Finish Options - Stainless Steel and Autograph Edition bundles are available
• ENERGY STAR® Rated - Enjoy energy savings while maintaining professional power with superior insulation and an energy-reducing cooling system
• Warranty - 2-year parts and labor warranty, 5-year parts-only sealed system warranty


Dimensions:	29.75 in. W x 23.3125 in. D x 83.5 in. H
Cut-Out Dimensions:	30.1875 in. W x 25 in. D x 84 in. H
Total Capacity:	16.1 cu. ft.
Fridge Capacity:	11.6 cu. ft.
Freezer Capacity:	4.5 cu. ft.
Flex Drawer Capacity:	2.7 cu. ft.25
Flex Drawer Temp Controls:	30°F (-1°C) - 41°F (5°C)
Installation Depth:	25 in. D
Depth with Door Open:	55.1 in.
Ice Maker:	Yes
Ice Maker Types:	Single Ice Maker
Ice Amount Per Day:	3.9 lbs
Ice Tray Storage (lbs.)	8.4 lbs
Water Dispenser:	Yes
Flow rate for Water Dispenser:	.5 GPM
Lights:	4 LED (3 fridge, 1 freezer)
Energy Star:	Yes
Energy Consumption (kWh/year)	551 kWh/year
Voltage:	120V/60Hz
Amps:	2.6A
Noise Level:	43 Decibels
Humidity-Controlled Crispers:	N/A
Freezer Drawer Bins:	2- Pull Out Drawers
Door Bins:	3
Number of Fridge Shelves:	3
Mount Type:	Built-In, Integrated
Certifications:	ETL Listed, ENERGY STAR certified
Material:	Panel Ready
Warranty	Manufacturing Warranty - 2-year parts and labor warranty, 5 years sealed system parts and labor
Weight	342.0
Ice/Water Dispenser Location	Internal
Replacement Filter Model Number	RBIV-205A
Lights	4 LED (3 fridge, 1 freezer)
Installation Depth	25"
Certifications	ETL Listed, Energy Star Certified
Warrant	Manufacturing Warranty - 2-year parts and labor warranty, 5 years sealed system parts and labor
Weight	342 lbs
