The Pioneer® Quantum Ultra™ 16,000 BTU Floor/Low-Wall Mounted Console Mini-Split delivers exceptional comfort and industry-leading efficiency with an impressive 23.8 SEER2 cooling rating and 13.5 HSPF2 heating performance down to -13°F.

Its sleek floor-level console design is ideal for rooms with limited wall space or under-window installations, while the variable-speed DC inverter and dual-axis motorized louvers provide precise, whisper-quiet airflow throughout the space.

Factory-precharged with eco-friendly R454b refrigerant and equipped with smart conveniences—ECO, SLEEP, TURBO, Self-Clean, MEMORY, and Follow-Me temperature sensing—this 230V heat pump system combines premium energy savings, reliable year-round performance, and effortless control for residential and light commercial spaces.

Summary

• High Efficiency Quantum Ultra Floor/Low-Wall Mounted Console Split Heat Pump System
• Cooling capacity: 16,000 BTU/H with 23.8 SEER2 / 12.5 EER2 efficiency
• Heating capacity: 17,000 BTU/H with 13.5 HSPF2 / 3.4 COP2 efficiency
• Voltage: 208/230V, 60Hz, 1Ph
• Floor/Low-Wall Mounted Console Ductless Air Conditioning & Heating System
• Variable-Speed DC Inverter Driven Performance
• Factory-Precharged with Environmentally Friendly R454b Refrigerant
• Standard Ambient Range Operation (As low as -13°F in Heating / As high as 131°F in Cooling)

Features

• Heat Pump with Cooling, Heating, Dry, and Ventilation Modes
• Dual-Drainage Ports
• Washable, Reusable Air Filters
• Dual-Axis Airflow (Motorized Up-Down and Left-Right Louvers
• Functional Remote with:
  • ECO and SLEEP Modes, for Energy-Conservation
  • Timer On/Off Control
  • TURBO, for Times of High-Demand
  • Self-Clean Cycle
  • MEMORY, to Recall Favorite Settings
  • FOLLOW ME, to Detect and Adjust to Local Temperature

Dimension Chart
